Place of Origin:
China
Nombre de la marca:
Hengyang
Certificación:
ISO9001
Model Number:
HY-01
Features:
1 .Removes small and large stones which are embedded in soil
2. Soil and mud remove from stone
3. Very efficient fast rate employed in separation process.
Technical Details:
| Model | HY0835 | HY1040 | HY1240 | HY1445 | 1HY645 | HY1850 | HY2050 |
| Slope (°) | 0-5 | 0-5 | 0-5 | 0-5 | 0-5 | 0-5 | 0-5 |
| Sieves Width | 40-100 | 40-100 | 40-100 | 40-100 | 40-100 | 40-100 | 40-100 |
| Practical Width (m) | 0.8 | 1 | 1.25 | 1.5 | 1.5 | 175 | 2 |
| Length (m) | 3.5 | 4 | 4 | 4.5 | 4.5 | 5 | 5 |
| Power (kw) | 7.5*2 | 11*2 | 15*2 | 15*2 | 18.5*2 | 22*2 | 30*2 |
| Capacity (t/h) | 60-0-100 | 100-150 | 150-200 | 200-300 | 300-400 | 400-600 | 600-800 |
| Hopper (m3) | 1.5 | 2 | 2.5 | 3 | 3 | 3.5 | 4 |
| Crawler Mobile Separator | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Layer | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Rotation Speed (r/min) | 0-180r/min (frequency control) | ||||||
| Blade shape | Triangle type, butterfly type, teeth shape, Octagonal | ||||||
| Assist air | Frequency control Blower | ||||||
| Oil Station | Provide power | ||||||
